PRODUCTS
OUR Product
"Play solid compatible Enjoy excellent features Feel the brand charm"
Keyhole sewing machine

Keyhole sewing machine has the characteristics of high efficiency, accuracy and stability

It can improve the production efficiency and ensure the quality and beauty of the seam

To provide users with convenient and reliable sewing solutions

  • PT-1790AN
    Keyhole sewing machine standard
    Direct drive motor, low noise.
    LED lights with adjustable junction brightness are provided on the lower side of the arm jaw.
    Equipped with a new stepping motor type automatic lifting device to reduce operator fatigue.
    Technical characteristics
    Sewing speed: 4,200sti/min
    When using unfed shuttle (optional) : 3,300sti/min
    Circular sewing: 20 different programs can be recorded, and each program can store 30 different patterns.
    Continuous sewing: Two or more different patterns can be continuously stitched without lifting the press cloth or foot.
    Click to see the detailed parameters
  • PT-1790AN-LXSL
    Continuous feed keyhole machine
    Stitch stability sewing precision is higher: needle swing and feed using stepper closed-loop motor drive, high precision, stitch stability.
    Technical characteristics
    Sewing speed: 4,200sti/min
    When using unfed shuttle (optional) : 3,300sti/min
    Bottom sewing process, beautiful stitch: with bottom sewing function, especially suitable for elastic fabric sewing, beautiful stitch without deformation.
    Multi-size buttonhole, no need to change the knife: In the case of no need to change the machine cutter, by several times to achieve the sewing of large size buttonhole.
    Click to see the detailed parameters
Button sewing machine

Nail stitch sewing machines are available in a variety of sewing modes and functional configurations

It can be adjusted and set according to different button types and sizes

Whether it is ordinary buttons, metal buttons, plastic buttons or various special shapes of buttons

Nail stitch sewing machines are flexible to meet the individual needs of users

  • PT-1903BN
    Staple sewing machine standard
    Sewing speed up to 2,700s ti /min. High-speed tangential, greatly reducing the total cycle time.
    Standard with 50 different sewing patterns, more efficient production.
    PT-1903B N is a flat stitching machine, suitable for a variety of sewing specifications, capable of circular sewing, with excellent sewing quality.
    Technical characteristics
    Zoom function: 20~200% (1% is the unit), you can increase/reduce the length of the stitch to enlarge/reduce the pattern.
    High accuracy: The button sewing machine can accurately fix the button and the fabric together, and the sewing button is strong and durable.
    Stability: Because the stitch sewing machine focuses on the stitch operation, its structure and design are simpler, the operation is relatively stable, and it is easy to use.
    Click to see the detailed parameters
  • PT-1903BN-AFC
    Hidden seam nailing machine
    PT-1903BN-AFC has increased the sewing of large and small buttons (child buttons) and expanded the range of applications.
    Both the sewing method and the sewing shape can be easily reset through the operating panel. By using Y feed on the operator side, X-Y feed on the button side, and independent drive mode of the swing needle, it can cope with the number of pin holes (four holes on the outer button and two holes on the inner button).
    Technical characteristics
    Usage: Sewing of various buttons (machine nail button)
    Surface tension adjustment: electronic clamp (special electronic surface tension control system)
    Number of sewing patterns: Number of registered patterns: 20 (30 patterns in one cycle)
    Needle: ORGAN SM×332EXTLG-NY (standard needle), (Factory #14) #12~#18
    Click to see the detailed parameters
Hitch sewing machine

Knot sewing machine can not only complete a variety of basic sewing tasks, but also has the function of knot

During the sewing process, the knotting operation can be carried out to enhance the firmness of the suture


  • PT-1900BN
    Hitch sewing machine
    Small AC servo motor direct drive head (no belt), excellent performance. Reduce vibration and noise to help create a comfortable working environment. The arm part of the machine head is provided with a manual pulley. Easy for the operator to view the drop point. Stitching point repair: When correcting the drop pin point of the nail buckle, the stitching point can be repaired without mechanical adjustment.
    Technical characteristics
    Sewing speed: 3,200s ti /min
    Press cloth press foot lift: standard 14mm (17mm when the reverse rotary needle function)
    Number of stored stitches: 20,000 stitches
    PT-1900BN can carry out knotting operation, make the stitching more firm, improve the sewing quality, suitable for some industries with high requirements for sewing quality.
    Click to see the detailed parameters
  • PT-1900BN-ZYJ
    Medium pressure foot knotting machine
    Double turning shuttle with half turning. In addition, the functions are enhanced, the external press foot is lifted higher, the direct drive head is responsive, the stop position is accurate, and the high-speed sewing performance and production efficiency are improved. The standard medium pressure foot prevents the fabric from moving, thus ensuring beautiful sewing. The lifting height and stroke of the press foot can be adjusted to quickly respond to changes in fabric thickness or layers.
    Technical characteristics
    Use: Medium thick material
    Needle length: 0.1mm~10mm (0.1mm unit)
    Sewing range: 60mm (length) ×100mm (width)
    Spinning shuttle: double capacity half-turning spinning shuttle
    Click to see the detailed parameters
  • PT-1900BN-SCZ
    Feed lining paper knotting machine
    High efficiency: It can quickly and continuously complete the knotting task of the lining paper, which is faster and more efficient than the manual knotting.
    Accuracy: Through accurate positioning and control system, accurate knotting operation can be achieved to ensure that the knotting position of the lining paper is accurate and uniform.
    Versatility: With a variety of hitch modes and functional configurations, providing a variety of flexible choices.
    Technical characteristics
    Use: Shirt, denim fabric
    Sewing range: 30mm (L) ×40mm (W)
    Press cloth press foot lift: standard 14mm(17mm when the reverse rotary needle function)
    Bottom line residual count: standard (up/down mode)
    Click to see the detailed parameters
  • PT-1900BN-FNC
    Anti bird nest knotting machine
    After sewing the cut line, in order to improve the quality of the product, the user will use scissors to cut the thread remaining on the fabric. This napping machine with anti-bird nest/short end function solves the problem of cutting the thread for the user, while preventing scissors from damaging the sewn product. Maintain thread length when sewing, and cut excess thread during sewing. Thus, the length of the stitching is shortened, the sewing quality is achieved, and the sewing thread entanglement on the opposite side of the "fabric" is prevented.
    Technical characteristics
    Sewing speed: 3,200s ti /min
    Sewing range: 30mm (L) ×40mm (W)
    Surface clamp: Electronic clamp (electronic surface tension control system)
    Zoom function: 20~200% (1% unit), you can enlarge/shrink the pattern by increasing/decreasing the length of the stitch.
    Click to see the detailed parameters
